Product Introduction
1500 knife grinding machine is a mechanical equipment specifically designed for grinding the cutting edges of tools. It has been widely applied in numerous industries such as wood processing, papermaking, plastics, rubber, and metal processing.
Primary data of knife grinder machine
|
Model |
HMZ1815 |
|
Magnet table length |
1500mm |
|
Magnet table width |
180mm |
|
Grinding accuracy |
≤0.05mm/m |
|
Work voltage |
380V,50HZ Or customerized |
|
Round tripTraveling-speed of tool grinding head |
Stepless speed 0-20m/min |
|
Magnet table adjustable angle |
±90° |
|
Grinding head adjustable angle |
±5° |
|
Grinding motor power |
4kw standard |
|
Lift motor power |
0.75kw |
|
Traveling motor power |
0.75kw |
|
Water pump power |
0.125kw |
|
total power |
5.625kw |
|
Grinding stone sped |
1440rpm |
|
Grinding stone size |
200x120x32mm |
|
Round trip speed of machine tool grinding head |
Continuously VariableTransmission 0-20 M/Min |
|
Overall Dimensions(mm) |
4030x1200X1450mm |
The composition of Crusher knife grinder
- Frame structure: Provides overall support to ensure the stability of the equipment.
- Grinding table: Place and fix the position of the cutting tool to maintain the accuracy during the grinding process.
- Grinding wheel: It is used for grinding cutting tools and is usually made of high-hardness materials.
- Electric motor: Drives the grinding wheel to rotate and provides grinding power.
- Tool fixture: Fix the tool to be ground to ensure precise angles and positions.
- Adjustment system: Adjust the Angle and position of the grinding table to ensure consistent grinding angles.
- Cooling system: To prevent the tool from overheating during grinding, it is usually cooled by coolant or water.
- Control panel: It is used to operate and control parameters such as the on/off and speed of the knife sharpener.
Maintenance method
- Clean the grinding wheel: Regularly remove wood or metal shavings from the grinding wheel to maintain the grinding effect.
- Check the motor: Inspect the motor's operating condition to ensure there is no abnormal noise or overheating.
- Lubricate mechanical components: Regularly apply lubricating oil to the slide rails and regulating systems to ensure smooth operation.
- Check the cooling system: Ensure that the cooling system is functioning properly to prevent the tool from overheating.
- Regularly inspect the tool fixtures: Ensure that the fixtures are tight and stable to prevent the tools from loosening during the grinding process.
- Inspect the grinding wheels: Observe the wear condition of the grinding wheels and replace those that are severely worn regularly.
